269-OPH01-02004

n/a

Optical Fiber OSP Suspension Clamp, Round ADSS, Self-supporting/Drop.

Description

Features :

      • Cable construction: round ADSS, self-supporting, or drop
      • Cable/messenger diameter: 0.6 in – 0.8 in (15 mm – 20 mm)
      • Load capacity: 4 kN (~900 lbf)
      • 100 m (~330 ft) max span
      • 25 ° max line/span angle
      • Rubber gripping insert, screw-adjustable compression
      • Galvanized steel (housing)
      • Neoprene (insert material)
      • Wall or pole using clamp anchor points (brackets)
      • Applications: Horizontal support
